Use Group

B

C

D

 Rated Voltage[V]

300

 -

300

 Rated Current [A]

12

 -

10

 Wire Range [AWG]

20~12

 Withstand Voltage

1.6KV

Technical Parameters

 Overvoltage Category

III

III

II

 Pollution Degree

3

2

2

 Rated Voltage[V]

250

320

630

 Rated Current[A]

24

24

24

 Rated Impulse Voltage[KV]

4

4

4

 Conductor Cross-sectional Area(Rigid/Flexible)[mm²]

0.25~2.5

Materials

 Insulation Material

PA66

 Flammability Rating

UL94-V0

 Conductor Material

Copper alloy

 Conductor Surface Plating

Sn plated

General Parameters

 Pitch/Number of Poles[mm]/[P]

10.0/1~30

 Stripping Length [mm]

10-11

 Screw/Torque(Max)[N.m]

/

 Operating Temperature [℃]

-40~+105

 Soldering Temperature

250℃/5S

 Pin Size[mm]

0.8*0.6

 PCB Hole Diameter[mm]

∅1.3
